1/2" Body Hydraulic Quick Connect Cartridge Coupler, Aftermarket Replacement for 4BD4FI Female FFI, Flat Face, ISO 16028, Heavy-Duty Hydraulic Coupling for Bobcat Manifold | Model TL60

This is an aftermarket replacement for manifold type flat face coupler with 46mm (about 1 13/16 inch) thread diameter (see images for measurement example). Fits many models of Bobcat, Kubota, Takeuchi, Case and other brands of skid steers, excavators and other machines equipped with a 4BD4FI* manifold Note: We have two different thread sizes available for Bobcat manifold type couplers. To determine which size/style you will need, measure the outside diameter of the thread, or take a close look at the style of o-rings in the images and compare to your original part. Application: Fits the following Bobcat Machines: Bobcat Skid Steer Loaders: 753, 763, 773, 863, 864, 883 A220, A300, A770 S130, S150, S160, S175, S185, S190, S205, S220, S250, S300, S330, S450, S510, S530, S550, S570, S590, S630, S650, S750, S770, S850 T140, T180, T190, T200, T250, T300, T320, T450, T550, T590, T595, T630, T650, T750, T770, T870 Excavators: 325, 328 Telescopic Handlers: TL35.70, TL360, TL38.70HF, TL470, TL470HF Work Machines: 5600, 5610 *Interchange Part Numbers: - 6680018 - V0511-77150 *Disclaimer: All third party trademarks (including logos and icons) referenced by TL Topline Inc. ("Topline") remain the property of their respective owners. Unless specifically identified as such, Topline's use of third party Trademarks does not indicate any relationship, sponsorship, or endorsement between Topline and the owners of these trademarks. Any References by Topline to third party trademarks and part numbers is to identify the corresponding third party goods and/or services and shall be considered nominative fair use under the trademark law. TL60 1/2" FLAT FACE CARTRIDGE COUPLER FOR 4BD4FI MANIFOLDS4BD4FI MANIFOLD COMPATIBILITY: The TL60 is a specialized flat-face cartridge coupler engineered specifically for use with 4BD4FI manifolds. Its low-profile design provides a secure connection for hydraulic systems used on skid steers, compact loaders, backhoe loaders, and other compatible equipment. Always verify the manifold type before installation.CONNECT-UNDER-PRESSURE CAPABILITY: The TL60 is designed to allow connection when residual pressure is present in the hydraulic line. This can simplify attachment changes when trapped pressure makes conventional couplers difficult to connect.HEAVY-DUTY ARCHITECTURE: Rated for 35 MPa (5075 PSI), the TL60 features a low-profile cartridge design that helps reduce side loading at the manifold connection. This provides a durable connection for demanding hydraulic applications.ULTRA-LOW SPILLAGE: Engineered for controlled fluid transfer, the TL60 has a specified spillage rate of 0.01 ml, helping minimize hydraulic fluid loss during connection and disconnection.SECURE LOCKING SYSTEM: The heavy-duty locking collar helps maintain a secure connection and helps prevent accidental disconnection during equipment operation and high-vibration applications.HIGH FLOW CAPACITY: With a rated flow rate of up to 100 l/min, the TL60 is designed to support hydraulic applications requiring consistent, high-volume fluid transfer.SPECIFICATIONS: Part Number: TL60 Compatibility: 4BD4FI Manifolds Coupler Body Size: 1/2" Dash Size: 8 Thread Outer Diameter: 46 mm Thread Type: SAE Maximum Working Pressure: 35 MPa (5075 PSI) Flow Rate: 100 l/min Operating Temperature: -40°C to 106°C (-40°F to 223°F) Coupler Plating: Zinc-plated Steel Package Includes: 1 Female Flat Face Cartridge CouplerFREQUENTLY ASKED QUESTIONS:Q: Is the TL60 compatible with all skid steer manifolds? A: No. The TL60 is specifically designed for 4BD4FI manifolds. Verify your equipment's manifold type and specifications before installation to ensure proper fitment.Q: What is the benefit of the connect-under-pressure functionality? A: Residual pressure trapped in hydraulic lines can make conventional couplers difficult to connect. The TL60 is designed to accommodate connection when residual pressure is present, helping simplify attachment changes and reduce the need to relieve trapped line pressure.Q: How does the low-profile design improve the connection? A: The low-profile cartridge design keeps the coupler closer to the manifold, helping reduce side loading and leverage forces at the connection point during equipment operation.Q: Is the TL60 suitable for extreme temperatures? A: The specified operating temperature range is -40°C to 106°C (-40°F to 223°F). Always confirm that the complete hydraulic system, seals, and other components are suitable for the intended operating conditions.Q: Can the TL60 be used for high-flow applications? A: The TL60 has a specified flow rate of up to 100 l/min, making it suitable for hydraulic applications requiring high-volume fluid transfer, provided the equipment and manifold specifications are compatible.

• 🗸 Size & Fit: 1/2" Body Hydraulic Quick Connect Cartridge Coupler, Aftermarket Replacement for 4BD4FI Female FFI, Flat Face, ISO 16028, Heavy-Duty Hydraulic Coupling for Bobcat Manifold | Model TL60
• 🗸 BUILT TO HANDLE PRESSURE: Rated for over 5075 PSI (350 bar) with a maximum flow rate of 100 l/min. Heavy-duty zinc-plated steel construction for long-lasting durability.
• 🗸 CONNECT UNDER PRESSURE: Features built-in connect-under-pressure functionality for fast, hassle-free hydraulic hookups in the field.
• 🗸 FLAT FACE DESIGN: Exceeds ISO 16028 standards, minimizes spillage (0.01 ml) and improves efficiency.
• 🗸 SECURE LOCKING COLLAR: Heavy-duty locking collar resists accidental disconnects and maintains a reliable seal under high pressure.
• 🗸 WIDE APPLICATION: Compatible with Bobcat skid steer loaders (753, 763, 773, S130-S850, T140-T870), excavators (325, 328), telescopic handlers (TL35.70, TL470HF), and utility work machines (5600, 5610).
